Optimize performance, enhance durability, and ensure reliability with our cutting-edge structural analysis tool

Overview

Structural Analysis
Software

Ansys offers structural analysis software solutions that enable engineers of all levels and backgrounds to solve complex structural engineering problems faster and more efficiently. With our suite of tools, engineers can perform finite element analyses (FEA), customize and automate solutions for structural mechanics challenges and analyze multiple design scenarios. By using our software early in the design cycle, businesses can save costs, reduce the number of design cycles and bring products to market faster.Having seamless capabilities to connect easily to other physics analysis, ANSYS structural analysis software is used throughout the industry to optimize design.

Products

Structures Products

Simulate stress, strain, and deformation to ensure product strength and reliability. Optimize designs for durability and performance under real-world operating conditions.

Mechanical

Solve broad structural analysis needs with a suite of finite element analysis (FEA) solutions that provides in-depth analysis of structural and coupled-field behaviors.

LS - Dyna

Engage with a powerful, explicit simulation tool with integration into Ansys Mechanical. A large array of capabilities and material models enable complex models with great scalability.

Motion

This multibody dynamic solver for analysis of rigid and flexible bodies is capable of accurate evaluation of physical events through the analysis of a whole system.

Capabilities

Key Feartures

Easily handle the complexity of varied design environments with a range of analytical tools that enable you to meet performance goals and ensure long-term reliability.

Workbench

Workbench enables connections between analysis systems. For example, a prestressed modal analysis or fluid structure analysis.

This capability includes connections to other Ansys products including Ansys CFD products, optimization solutions and external CAD systems.

Strength Analysis

The strength of components sits as a key requirement in understanding a product’s performance, lifecycle and possible failure modes.

Mechanical loading, thermal stress, bolt tension, pressure conditions and rotational acceleration are just some of the factors that dictate strength requirements for materials and designs. Our products ensure your product’s viability and safety by predicting the strength required for the loads your design will experience in service.

Vibration

Vibration can be an undesired side effect of poor product design or the environment in which the product is operating.

It can have a substantial impact on durability and fatigue, leading to a shorter service life. You need to understand how your designs will respond to vibrations from phenomena such as brake squeal, earthquakes, transport and acoustic and harmonic loads to predict the behavior of products and components. Structural simulations can provide this understanding and help you to overcome your toughest vibration challenges.

Thermal Analysis

The effects of heat and thermal management on parts and assemblies is becoming increasingly critical as performance limits are pushed further by the need to have lighter, smaller and more efficient designs.

Convection, radiation and conduction loads are obvious, but the need to include the effect of power losses and thermal energy from friction and external sources such as pipe flows means that analysts need to have more tools at their disposal to simulate thermal models accurately.

Durability

Building durable products is key to reducing warranty costs and increasing reliability. Being able to understand how designs will behave over time as load cycles increase helps you avoid unexpected failures.

Fatigue or lifing analysis is a key enabler in building this product durability knowledge.

Impact

Impact between two or more bodies is modeled by the Ansys structural family of programs, including mechanical, explicit dynamics and rigid body dynamics.

Drop tests are ideal candidates for an impact analysis. These impact analysis programs calculate the forces between two or more colliding bodies and the resultant deformation or damage.

Structural Optimization

Ansys optimization technology includes parametric, shape (mesh morphing) and topology optimization.

It enables you specify where supports and loads are located on your model and lets the software explore the design space. For example, you can easily perform lightweighting of structures, extract CAD shapes quickly and explore designs and process parameters for additive manufacturing.

Rigid and Multi Body Dynamics

Mechanical devices can contain complex assemblies of interconnected parts undergoing large overall motions.

Examples could include suspension assembles in ground vehicles, robotic manipulators in manufacturing processes or gear systems within electric drivetrains. Simulating the motion of these systems gives insight into their performance over the range of dynamic loading experienced when in operation.

Hydrodynamics

Offshore structures are subjected to environmental loading from the effects of waves, currents and wind.

The design requirements for these structures can be quite different from traditional land-based constructions. Simulating the loading and the effects of these factors on structural response is a necessary component of the design. Ansys provides capabilities that can reproduce these loading conditions and responses across a broad range of applications. Ansys has solutions for different requirements depending on the specific application, from simplified models for truss type structures to high-fidelity simulations that include all aspects of the fluid loading environment.

Composites

The light, strong and versatile properties of composite materials make them attractive for many types of manufacturing.

Composite materials like carbon fiber, typically used in the aerospace and automotive sectors, are being used increasingly in energy, sports, construction and marine applications. Their composite nature, however, makes accurate simulation a challenge. Ansys offers a complete suite of tools to help you overcome this challenge.

Additive Manufacturing

Ansys Additive Solution delivers the critical insights required by designers, engineers and analysts for a successful Additive Manufacturing Process, to avoid build failures and create parts that accurately conform to design specifications.

This comprehensive solution spans the entire workflow — from design for additive manufacturing (DfAM) through validation, print design, process simulation and material analysis.

Multiphysics

A vast range of multiphysics capabilities from simple thermal structural analysis to coupled field analyses using finite element analyses are available.

Our entire Ansys portfolio looks at the effects of electromagnetic, structural, fluid and thermal forces in combination. As a result, it predicts product performance with greater accuracy and provides seamless data transfer between physics solutions.

Visioneering
